DRIP SOURCE
REVISED LIGHTING PLAN
FOR CONTRACTOR/ELECTRICIAN
10-9-24
ITEMS NOT INCLUDED
IN HOME DEPOT CART
MUST BE ORDERED:
RECEPTION DESK
MUST BE ORDERED:
DECORATIVE PVC SCREEN
APPROXIMATE SIZES
(1) LARGE SCREEN (31 3/8”W X 79 3/8"“H) FLOATING IN CENTER FRAME IN HALL BY DRIP ROOM ($88 EA) = $88.00
(4) (17 3/8”W X 44 3/8”H) FOR NURSE STATION & LARGE ROOM IN REAR ON LEFT ($34 EA) - $136.00
(2) STACKED ON TOP OF EACH OTHER NEXT TO DESK
MUST BE ORDRERED:
RECEPTION AREA FLUSH MOUTN LIGHT
(1) $208.99
PAINT MUST BE ORDERED
ALL ITEMS BELOW IN
HOME DEPOT CART
(4) TOTAL, (2) SIDE BY SIDE ABOVE NURSE DESK IN HALL & (2) ABOVE & LARGE BACK ROOM ON LEFT
$177. EA = $708
(2) NURESE STATION & LARGE BACK ROOM ON LEFT
(2) 174.33 EA = $348.66
(2) 1 ABOVE EACH STATION (SEE BELOW) IN THE 2 SMALL ROOMS
(2) $250. EA = $500.00
(2) 1 IN EACH OF THE 2 SMALL ROOMS
(2) 141.93 EA = $283.86
PRE-HUNG DOOR 30” X 80” (5) @ $109. = $545.00
SATIN NICKEL DOORKNOB (5) @ $15,49 = $77.45
PAINT COLORS
(21) RECESSED PINSPOTS FOR RECEPTION, DRIP ROOM AND PATIENT ROOMS
(24 pack $207.00)
(6) WALL WASHERS FOR RECEPTION & HALL ( 6 pack $169.00)
PRE-FAB RECEPTION DESK (RIGHT EXIT) 78.74inx23.6inx39.4in
(1) $1089
DIMMERS 6 @ $31.33 = $187.97
